Overview of High Purity Aluminum Nitride Ceramic Sheet Wafer

Aluminum Nitride (AlN) ceramic is an advanced technical ceramic material known for its unique combination of extremely high thermal conductivity and excellent electrical insulation properties. Unlike traditional alumina or beryllium oxide ceramics, AlN offers a thermal conductivity close to that of metals like aluminum and copper, while still acting as a robust electrical insulator. It is typically produced via powder processing and sintering, resulting in a dense, hard, and durable material ideal for demanding thermal management applications.

Features of High Purity Aluminum Nitride Ceramic Sheet Wafer

High Thermal Conductivity: Possesses a theoretical thermal conductivity of up to 320 W/m·K, with commercial grades typically ranging from 170 to 230 W/m·K, effectively dissipating heat in high-power circuits.

Excellent Electrical Insulation: Despite its metal-like heat transfer, it maintains a high volume resistivity and dielectric strength, preventing short circuits and ensuring device safety.

Low Thermal Expansion Coefficient (CTE): Its CTE closely matches that of silicon (Si) and Silicon Carbide (SiC), minimizing thermal stress and improving reliability in semiconductor packaging.

High Mechanical Strength & Corrosion Resistance: It offers good flexural strength and is resistant to attack from many molten metals and chemicals.

Non-Toxic: AlN is a safe alternative to Beryllium Oxide (BeO) ceramics, which pose serious health risks during processing and disposal.

Specification of High Purity Aluminum Nitride Ceramic Sheet Wafer

High Pureness Light Weight Aluminum Nitride Porcelain Sheet Wafer

Material Structure and Purity

This ceramic sheet wafer is made from light weight aluminum nitride (AlN) with a purity degree of 99.5% or greater. It has extremely reduced levels of oxygen and metal impurities. The high purity makes certain exceptional thermal and electric performance. Each set goes through strict quality assurance to satisfy market criteria.

Thermal Conductivity

Light weight aluminum nitride sticks out for its high thermal conductivity. This product generally achieves thermal conductivity in between 170– 220 W/m · K. That makes it suitable for applications needing reliable heat dissipation. Unlike typical ceramics, it transfers warm quickly without shedding architectural stability.

Electric Insulation

The wafer uses solid electric insulation even at heats. Its dielectric strength exceeds 15 kV/mm. Quantity resistivity remains over 10¹⁴ Ω · cm up to 300 ° C. These buildings support trusted efficiency in power electronic devices and semiconductor product packaging.

Mechanical Characteristics

This ceramic preserves excellent mechanical toughness and hardness. Flexural strength varieties from 300 to 400 MPa. Vickers hardness relaxes 12 GPa. The product withstands wear and keeps its form under stress and anxiety. It also reveals low thermal growth, very closely matching silicon and gallium arsenide.

Surface Area High Quality and Capacities

Wafers come with smooth, flat surface areas appropriate for thin-film deposition and bonding processes. Criterion density choices consist of 0.25 mm, 0.38 mm, 0.5 mm, and 1.0 mm. Custom sizes are available upon demand. Side chipping and surface area problems are minimized via precision machining.

Applications

These wafers are commonly utilized in LED substratums, RF devices, laser diodes, and high-power IC plans. They serve well in aerospace, vehicle electronic devices, and industrial sensing units where warm management and reliability issue many. Their compatibility with metalization procedures allows simple integration right into complicated systems.

Applications of High Purity Aluminum Nitride Ceramic Sheet Wafer

Applications of High Pureness Aluminum Nitride Ceramic Sheet Wafer

Electronic devices and Semiconductors

High pureness light weight aluminum nitride (AlN) ceramic sheet wafers are widely made use of in electronics. Their strong thermal conductivity assists move heat far from sensitive parts. This maintains tools running smoothly also under hefty use. AlN wafers likewise have exceptional electrical insulation. That makes them suitable for power components, LED substrates, and RF parts where heat control matters most.

Optoelectronics

In optoelectronic systems like laser diodes and UV LEDs, handling warmth is vital. Common products frequently fail under heats or extreme light. AlN wafers remain stable. They do not warp or deteriorate conveniently. Their wide bandgap and openness to ultraviolet light assistance much better performance in these requiring applications.

Aerospace and Defense

Equipment made use of in aerospace and protection must work accurately in severe problems. AlN ceramic wafers manage high temperatures, rapid temperature modifications, and rough settings without losing function. They are utilized in sensing units, radar systems, and interaction hardware that need both longevity and accuracy.

Medical Tools

Clinical devices such as imaging systems and medical tools call for tidy, secure products. High pureness AlN wafers fulfill stringent biocompatibility standards. They also withstand rust from cleaning representatives and body fluids. Their thermal residential or commercial properties assist preserve regular operation throughout lengthy procedures.

R & d

Scientists utilize AlN wafers in labs to examine new semiconductor layouts and advanced materials. The material’s pureness makes sure precise results. Its mechanical strength allows it to be shaped into customized forms for speculative arrangements. Scientists count on it when consistency and reliability are non-negotiable.

Company Introduction

Welcome to Eduloc, a leading global supplier of high-quality ceramic grinding balls. Our product range includes,Mullite Ceramic, Quartz Ceramic, Aluminum Nitride Ceramic, Silicon Nitride Ceramic, Silicon Carbide Ceramic designed for industries such as mining, chemicals, coatings, electronics, and pharmaceuticals. We are committed to providing durable and efficient grinding solutions tailored to our customers’ diverse needs. With advanced manufacturing technology and stringent quality control, our ceramic grinding balls excel in wear resistance, corrosion resistance, and thermal stability. Partner with us for reliable products and exceptional service that enhance your production efficiency and reliability.

If you have any questions, please feel free to contact us.

Payment Methods

T/T, Western Union, Paypal, Credit Card etc.

Shipment Methods

By air, by sea, by express, as customers request.

5 FAQs of High Purity Aluminum Nitride Ceramic Sheet Wafer

What is a high purity aluminum nitride ceramic sheet wafer?

High purity aluminum nitride ceramic sheet wafers

These are thin, flat pieces made from aluminum nitride (AlN) with very few impurities—usually over 99.5% pure. They offer excellent thermal conductivity and strong electrical insulation. This makes them ideal for use in electronics that need to manage heat well without conducting electricity.

Why choose aluminum nitride over other ceramic materials?

Better heat control and performance

Aluminum nitride moves heat away much faster than common ceramics like alumina. It also stays stable at high temperatures and does not expand or shrink much when heated or cooled. These traits help electronic parts last longer and work more reliably.

Where are these wafers commonly used?

Key applications in advanced tech

You’ll find them in power modules, LED lighting, RF devices, and semiconductor packaging. Any system that creates a lot of heat but must stay electrically isolated often uses AlN wafers. Their performance supports miniaturization and higher efficiency in modern electronics.

How is the purity of the wafer ensured?

Strict production controls

Manufacturers use high-grade raw materials and controlled sintering processes in clean environments. Each batch goes through testing to confirm purity levels, density, and thermal properties. This ensures consistent quality across every wafer produced.

Can these wafers be customized?

Fits your specific needs

Yes. You can get them in different thicknesses, sizes, and surface finishes. Some suppliers also offer laser cutting or metallization for direct bonding. Just share your design specs, and they can tailor the wafer to match your application exactly.
